Floor Shot Blasting Machine for Concrete Surface Prep Equipment

What Is a Floor Shot Blasting Machine?

A floor shot blasting machine is a mobile surface-preparation machine that uses high-speed steel shot to impact concrete, steel, asphalt, bridge decks, and other suitable surfaces.

It is also called a:

Floor shot blaster
Concrete shot blaster
Road shot blasting machine
Concrete floor bead blaster
Surface preparation shot blaster
Bridge deck shot blaster

During operation, the blast wheel accelerates steel shot toward the surface. The impact removes or weakens suitable coatings, laitance, loose material, rust, scale, contaminants, and surface residue. The machine then recovers the abrasive and directs dust and removed material toward the connected dust collector.

This is not the same as simply making a floor look cleaner. The goal is often to create a surface condition suitable for the next process, such as:

Epoxy flooring
Polyurethane coating
Waterproofing membrane application
Anti-slip treatment
Bridge deck waterproofing
Industrial floor restoration
Pavement marking removal
Steel coating preparation
Floor overlay preparation

The required result varies by coating system and project specification. A surface that appears clean may still have the wrong texture, moisture level, contamination condition, or adhesion condition for the next coating.

Would you like to learn more about our products? Contact us now to get more information.

Get a Factory-Direct Quote on Floor Shot Blasters

How to Choose Between YG-270, YG-550/600, and YG-850 Floor Shot Blaster Machine

YG offers several floor shot blasting machine configurations for different working widths, access conditions, and production targets.

Specification	YG-270 Single	YG-550/600 Double	YG-850 Double
Recommended project type	Corridors, narrow areas, small repairs, access-restricted zones	Medium industrial floors, parking areas, bridge decks, standard preparation projects	Large warehouses, factories, long work lanes, high-volume floor preparation
Working width	270 mm	550/600 mm	800 mm
Walking speed	0.5–20 m/min	0.5–33 m/min	0.5–33 m/min
Concrete cleaning efficiency	≥180 m²/h	≥400 m²/h	≥600 m²/h
Steel plate cleaning efficiency	15–25 m²/h	75–100 m²/h	100–160 m²/h
Blast wheel diameter	200 mm	200 mm	200 mm
Blast wheel motor	11 kW	2 × 11 kW	2 × 15 kW
Walking motor	0.5 kW	1.5 kW	1.5 kW
Suggested steel-shot size	1.2–1.5 mm	1.5–1.8 mm	1.5–1.8 mm
Reference steel-shot consumption	Approx. 10 g/m²	Approx. 10 g/m²	Approx. 10 g/m²
Dust hose diameter	120 mm	150 mm	150 mm
Suggested dust collector	Seven-core automatic pulse-cleaning collector	Eight-core automatic pulse-cleaning collector	Eight-core automatic pulse-cleaning collector
Approximate machine dimensions	1000 × 300 × 1100 mm	1950 × 720/775 × 1400 mm	1950 × 1020 × 1550 mm
Approximate machine weight	150 kg	570 kg	700 kg
Reference power requirement	400 V / 50 Hz / 100 A CEE	400 V / 50 Hz / 100 A CEE	400 V / 50 Hz / 100 A CEE

Choose YG-270 When Access Matters Most

The YG-270 Single can be considered for smaller areas, narrow paths, repair zones, corridors, or projects where the machine must move through constrained access routes.

Its narrower working width may be helpful where a larger machine cannot work efficiently. However, a narrow machine does not remove the need to plan edge treatment, dust collection, power access, and coating-specification checks.

Choose YG-550/600 for Balanced Production

The YG-550/600 Double can be considered for medium-scale industrial floors, parking structures, road maintenance sections, bridge decks, and common coating-preparation projects.

This size can provide a practical balance between working width, mobility, and production potential for contractors who handle varied job types.

Choose YG-850 for Large, Open Areas

The YG-850 Double can be considered for large industrial floors, warehouses, factories, long straight lanes, and projects with enough access space to support a larger machine and dust-collection setup.

It is not automatically the correct choice for every large project. If the site has many columns, drains, walls, tight turns, interrupted work zones, or complex edge treatment, the total project pace may still depend heavily on secondary tools and manual finishing.

Get Factory Direct Pricing Today

Floor Shot Blasting Machine vs Grinding vs Scarifying vs Sandblasting

Different surface-preparation methods solve different problems. They should not be presented as identical alternatives.

Method	Often Used For	Main Strength	Main Limitation
Floor shot blasting machine	Coating removal, laitance removal, surface profiling, bridge deck preparation, large-floor work	Closed abrasive recovery process and consistent travel path on suitable surfaces	Does not finish all edges, corners, drains, or severely damaged areas
Floor grinding	Smoothing, leveling, thin-coating removal, polishing, and local edge work	Good control for smoothing and edge finishing	May not create the same profile or removal result as shot blasting
Scarifying/milling	Thick coating removal, high spots, damaged concrete, deep material removal	More aggressive removal for selected conditions	Can create a rougher texture and may require additional preparation
Portable sandblasting machine	Small areas, repairs, corners, irregular shapes, and localized work	Flexible for difficult geometry	More containment and cleanup planning may be required
Dry ice blasting machine	Residue-sensitive cleaning, equipment maintenance, and low-secondary-residue cleaning	Does not leave abrasive media behind	Usually not a direct substitute for aggressive concrete profiling or coating-anchor preparation
Pass-through shot blasting machine	Steel plates, beams, profiles, pipes, and factory production lines	Continuous treatment of fabricated steel workpieces	Not designed for mobile floor or road-surface work
Sandblasting room/blast room	Large, irregular, non-movable, or complex workpieces	Controlled enclosed blasting for industrial components	Not a mobile solution for floors, roads, or bridge decks

YG can provide different surface-preparation equipment because a contractor may have both site-based and factory-based work. The correct solution depends on whether you are treating a floor, road, bridge deck, steel plate, structural member, machinery component, or irregular fabricated workpiece.

Request a Budgetary Quote for Your Project – Fast Response

Why Choose YG Machinery Concrete Shot Blaster?

YG Machinery supports contractors, rental companies, distributors, and industrial buyers looking for a surface-preparation solution based on real project requirements.

Model Selection Based on Your Surface Condition

YG can help compare the YG-270, YG-550/600, and YG-850 according to:

Substrate type
Coating condition
Working area
Required preparation result
Access route
Available electrical supply
Dust-control requirement
Operating environment
Project schedule

Export and Support Planning

For overseas orders, equipment selection should include:

Local voltage, frequency, and plug requirements
Dust collector configuration
Steel-shot specification and local supply
Export packing and container loading
Wear-part package
Operator documentation
Remote technical communication
Training preparation
Maintenance planning

Final support scope, warranty terms, delivery schedule, and included accessories should be confirmed in the final quotation and contract.

Get a Custom Solution for Your Floor Size – Ask Engineer

Plan Your Surface Preparation Workflow With YG

A floor shot blasting machine should be selected based on your substrate, coating system, required finish, work area, dust limits, electrical supply, and edge-work requirement—not only around a quoted square-meter figure.

Send your floor photos, coating type, and required finish for a more relevant recommendation.

Please provide:

Total work area in square meters
Substrate type: concrete, steel plate, asphalt, bridge deck, or other
Existing coating type and approximate thickness
Target coating, waterproofing, anti-slip system, or removal objective
Required surface profile or project specification
Indoor or outdoor work environment
Ventilation and dust-control limits
Available voltage, frequency, current, and plug type
Floor plan and access dimensions
Percentage of wall edges, columns, drains, joints, ramps, and obstacles
Surface damage, cracks, oil contamination, or moisture concerns
Required production schedule
Destination country and port
Expected purchasing timeline

Get a Floor Shot Blaster Model Recommendation from YG Machinery for concrete preparation, bridge deck work, industrial floor coating removal, and road-surface treatment.
