What Is a Dredge Machine for Shrimp Farm?
A dredge machine for shrimp farm is a compact, remotely controlled dredging unit designed to remove accumulated sludge, sediment and organic waste from the bottom of aquaculture ponds. It typically consists of a crawler-type robot body, a hydraulic dredging pump, a cutter or agitation mechanism, and a discharge pipeline — all operated via wireless remote control from the pond bank.
How it differs from other approaches:
- vs. manual labor: A shrimp pond sludge removal machine processes 50–250 m³/h of slurry, replacing dozens of workers with 1–2 operators
- vs. conventional excavators: The compact crawler design enters ponds through standard access points (≥600 mm openings), works in water as shallow as the pond floor allows, and does not damage pond liners or banks
- vs. large marine dredgers: Floating and compact crawler dredgers are built for shallow aquaculture ponds (typically 1–3 m depth), where full-size dredging vessels cannot operate
The machine travels along the pond bottom using hydraulic crawler tracks, suctioning loosened sludge through the pump and discharging it via pipeline to a designated dewatering or disposal area.
If you are interested in dredging robots, please contact us now for more product information.
Click to Learn More About YG Dredge Machine Details
Technical Parameters of YG’s Remote-Controlled Tracked Dredging Robot
| Model | YG-500 | YG-600 | YG-700 | YG-800 | YG-900 | YG-1200 |
| Robot dimensions | 1500*500*650mm | 1500*600*650mm | 1600*700*650mm | 1600*850*700mm | 1650*960*750mm | 1900*1200*750mm |
| Dredging width | 500mm | 600mm | 700mm | 800mm | 900mm | 1200mm |
| Track travel speed | 3-15m/s | 3-15m/s | 3-15m/s | 3-15m/s | 3-15m/s | 3-15m/s |
| Robot weight | 320kg | 350kg | 380kg | 400kg | 420kg | 500kg |
| Pump output diameter | 3inch | 3inch | 4inch | 4inch | 4inch | 4inch |
| Pump flow rate(cubic meters/ hour) | 100 m³ | 100m³ | 200m³ | 200m³ | 200m³ | 200m³ |
| Hydraulic station dimensions(mm) | 2200*1200*1700 | 2200*1200*1700 | 2200*1200*1700 | 2200*1200*1700 | 2200*1200*1700 | 2120*1240*1200 |
| Main motor power | 22kw | 22kw | 30kw | 30kw | 30kw | 45kw |
| Hydraulic system pressure | 0-16Mpa | |||||
| Particle size | 15mm | 15mm | 38mm | 38mm | 38mm | 60mm |
| Reeling system speed | 0-10r/min | |||||
| Hydraulic hoses | 50m (Standard configuration) | |||||
| Control system | Wireless remote control | |||||
| Lighting system | Underwater LED lights *2 | |||||
Model selection guide by pond size:
- Small ponds (up to 0.5 ha): YG450–YG500, pump flow 50–100 m³/h
- Medium ponds (0.5–2 ha): YG600–YG800, pump flow 100–160 m³/h
- Large ponds (2+ ha): YG900–YG1200, pump flow 200–250 m³/h
[Need detailed drawings, load charts, or a model comparison? Contact our engineering team.]
Get Full Technical Specs About Dredging Robots
Why Shrimp Farms Need Pond Dredging?
Pond bottom management is one of the most overlooked aspects of shrimp farm operations — until problems become severe. Here is what happens when sludge accumulates without intervention:
Organic waste buildup
Each production cycle deposits layers of uneaten feed, shrimp feces, molted shells, and dead algal biomass on the pond floor. In intensive systems, this layer can reach 20–50 cm within a single year.
Reduced effective water depth
As sediment builds up, the actual water volume decreases. A pond designed for 1.5 m depth may operate at only 1.0–1.2 m after several cycles without dredging — directly affecting stocking density and water circulation.
Toxic gas generation
Anaerobic decomposition of organic sludge produces hydrogen sulfide (H₂S) and ammonia (NH₃). Field data from shrimp farms show H₂S concentrations exceeding 0.05 ppm in heavily silted ponds — well above levels that cause stress and mortality in shrimp.
Disease pressure
Thick bottom sludge creates anaerobic microenvironments where pathogenic bacteria such as Vibrio spp. thrive. Regular sludge removal is a preventive measure, not a reactive one.
Pond renovation between cycles
Most commercial farms practice periodic pond drying and renovation between production cycles. Removing accumulated sludge is a mandatory step in this process — the faster and more thorough the cleaning, the shorter the turnaround time.
Reduced reliance on manual labor
Manual pond cleaning requires teams of workers wading through knee-deep sludge — slow, physically demanding, and increasingly difficult to staff in many regions.
A dredge machine for shrimp farm addresses all of these issues with mechanized, consistent, and repeatable sludge removal — without draining the pond or disrupting adjacent operations.
Schedule a Factory Tour / Virtual Tour
11 Key Features of the Yugong Machinery Underwater Dredging Robot
- Crawler-based underwater design. The robot travels on reinforced tracks along the pond bottom, providing stable movement across uneven sludge layers. Unlike floating-only systems, the crawler maintains consistent contact with the pond floor for thorough cleaning.
- Suitable for shallow shrimp ponds. Designed for the typical 1–3 m water depth of commercial shrimp ponds. The low-profile robot body operates in conditions where standard dredging equipment cannot reach.
- Hydraulic cutter and suction pump. A rotating cutter head loosens compacted sludge before the pump suctions it into the discharge pipeline. This two-stage approach handles both soft organic sludge and semi-compacted sediment layers.
- Adjustable working depth. Pump intake height can be adjusted to control how much sludge is removed in each pass — useful for farms that need partial cleaning or want to avoid disturbing the pond liner.
- Continuous sludge removal. The system operates continuously: cutting, suctioning, and discharging in one flow. There is no need to stop, reposition, or reload — which significantly increases coverage per hour compared to batch methods.
- Easy transport between ponds. The robot unit is compact enough to move between ponds on a standard trailer or by manual handling. For multi-pond farms, one machine can serve several ponds in sequence.
- Wireless remote control. All movement, pump operation, and cutter functions are controlled remotely from the pond bank. This keeps operators out of the water and away from potential gas exposure.
- Diesel, electric, or hydraulic power options. Power station configurations vary by model — electric drive for farms with grid access, diesel for remote locations without power infrastructure.
- Corrosion-resistant components. Pump impellers, cutter heads, and structural elements use stainless steel or high-chrome alloy materials to resist corrosion from saltwater and brackish pond environments.
- Customizable discharge pipeline length. Pipeline sections can be configured from 20 m to 50+ m depending on the distance between the pond and the sludge disposal area.
- Optional dewatering or sludge separation system. For farms that need to reduce sludge volume before disposal or recover usable material, a dewatering system can be added downstream.
Not Sure Which Model Fits Your Application? Click Here Now
Suitable Applications of the Sediment Dredging Robot
Well-suited for:
- Earthen shrimp ponds — standard earthen-bottom ponds where sludge accumulates on natural soil surfaces.
- Lined shrimp ponds — HDPE-lined ponds where the crawler design avoids damaging the liner.
- Intensive aquaculture ponds — high-density farming systems with significant organic buildup per cycle.
- Semi-intensive shrimp farms — moderate stocking density ponds requiring periodic maintenance.
- Nursery ponds — smaller preparation ponds that need thorough cleaning before restocking.
- Post-harvest sediment removal — routine cleaning between production cycles.
- Pond re
- novation and deep cleaning — removing years of accumulated sediment before major overhaul.
- Multiple-pond aquaculture farms — one machine rotating across several ponds on schedule.
May require further evaluation for:
- Extremely rocky pond bottoms — hard rock formations may limit cutter effectiveness.
- Very narrow pond access — ponds with no access opening larger than 500 mm may not accommodate even the smallest model.
- Heavy floating debris — large timber, nets, or structures on the pond surface should be cleared first.
- Highly contaminated industrial sludge — chemical contamination requires specialized handling beyond standard aquaculture dredging.
- Areas requiring special environmental permits — discharge regulations vary by region; confirm local requirements before operation.
Comparison Table of Dredge Machine Vs. Other Cleaning Methods
| Comparison Dimension | Manual Sludge Removal | Excavator | High-Pressure Water Cleaning | Conventional Large Dredger | Dredge Machine for Shrimp Farm |
| Labor requirement | High (10–20+ workers) | Low (1–2 operators) | Medium (3–5 workers) | Low (2–3 operators) | Low (1–2 operators) |
| Shallow-water suitability | Moderate (workers wade in) | Poor (tracks damage bottom) | Good | Poor (too large for shallow ponds) | Excellent (designed for 1–3 m) |
| Pond-bank impact | Low | High (tracks and bucket contact banks) | Low | High (large vessel displacement) | Low (compact crawler, controlled movement) |
| Mobility between ponds | Workers walk | Requires transport between ponds | Equipment is movable | Difficult — large units | Easy — trailer or manual move |
| Cleaning efficiency | Low (slow, inconsistent) | Medium–High | Medium (loosens but doesn’t remove) | High (but oversized for shrimp ponds) | High (50–250 m³/h, systematic) |
| Operating cost per session | High (labor costs) | Medium–High (fuel + transport) | Medium | High | Medium (fuel/electricity + 1–2 operators) |
| Pond liner protection | Moderate risk | High risk of damage | Low risk | High risk | Low risk (designed for lined ponds) |
| Best use case | Very small ponds, spot cleaning | Large-scale earthwork, bank reshaping | Light maintenance, surface agitation | Large water bodies, harbors | Shrimp farm ponds of all sizes |
Key takeaway: For shrimp ponds specifically — shallow water, multiple ponds, frequent cleaning cycles, and liner protection requirements — a purpose-built dredge machine offers a balance of efficiency, access, and care that general-purpose equipment does not match.
View Real-World Case Studies of Dredge Robot
How to Choose the Right Shrimp Pond Dredger?
Use this checklist when evaluating a dredge machine for your farm:
Pond assessment:
- ☐ Pond dimensions (length × width × depth)
- ☐ Average water depth during operation
- ☐ Estimated sludge thickness (measure with a probing rod if possible)
- ☐ Sludge composition (soft organic sludge, sandy sediment, mixed)
- ☐ Pond bottom type (earthen, HDPE-lined, concrete)
- ☐ Access opening size (gate, culvert, or open edge)
Performance requirements:
- ☐ Required dredging capacity (m³/h based on pond size and cleaning frequency)
- ☐ Discharge distance (from pond to sludge disposal area)
- ☐ Available power source (grid electricity, diesel generator, or both)
- ☐ Number of ponds to be serviced by one machine
Site conditions:
- ☐ Transport conditions between ponds (road width, bridge capacity)
- ☐ Sludge disposal area location and type (settling pond, dewatering bags, agricultural land)
- ☐ Local environmental and discharge regulations
Operational factors:
- ☐ Frequency of pond cleaning (between every cycle, annually, every 2–3 years)
- ☐ Available trained operators
- ☐ Spare parts and service support in your region
When requesting a quotation, provide:
- Pond dimensions and total number of ponds
- Photos or videos of pond conditions (especially sludge thickness)
- Current water depth
- Estimated sludge thickness
- Required discharge distance
- Expected cleaning volume per season
- Destination country (for shipping and compliance)
Get a Free Custom Solution of Dredge Robot
Frequently Asked Questions: YG’s Dredging Robots for Cleaning Sludge
A1: The right model depends on your pond size, sludge thickness, and cleaning frequency. Smaller ponds (under 0.5 ha) typically suit the YG450–YG500 range (50–100 m³/h), while larger operations benefit from YG800–YG1200 models (160–250 m³/h). Share your pond details with our team for a specific recommendation.
A2: Yes. These machines are specifically designed for shallow aquaculture ponds, typically 1–3 meters deep. The compact crawler robot operates on the pond bottom in water depths where conventional equipment cannot function.
A3: A crawler-type robot moves along the pond bottom while a rotating cutter head loosens compacted sludge. A hydraulic pump then suctions the loosened material and discharges it through a pipeline to a designated area on the pond bank. The entire system is operated remotely via wireless control.
A4: Price depends on model, pump capacity, power source, pipeline length, and configuration. Additional factors include shipping costs and destination. For an accurate quotation, please submit your pond specifications — we provide custom quotes based on actual project requirements.
A5: This varies by farming intensity and management practices. Many commercial farms dredge between every production cycle (every 3–6 months). Some operations with lighter buildup may clean annually. Farms practicing continuous stocking without full draining may need mechanical dredging every 1–2 years. Regular dredging prevents extreme accumulation and reduces per-session cleaning time.
A6: Yes. The cutter head and pump system are designed to handle organic sludge (feed residue, feces, biofloc, dead algae), semi-compacted sediment, and mixed sludge layers. Particle size capacity varies by model, from ≤15 mm for smaller units to 40–50 mm for larger models.
A7: Pond dimensions (length × width × depth), sludge thickness, number of ponds, discharge distance, available power source, and destination country. Photos or videos of the pond and sludge conditions are very helpful for accurate recommendations.
A8: Yes. Options include different pump capacities, pipeline lengths, power source configurations (electric/diesel), and cutter head specifications. Contact our engineering team to discuss your specific requirements.
