The HZ core drilling rig, commonly known as the HZ-type core drilling rig or HZ coring rig, is a specialised drilling device used for core sampling and formation exploration. It belongs to a core sub-category of core drilling equipment and is a mainstream model within rock core drilling equipment. Its core function is to accurately obtain underground rock samples, providing reliable data support for engineering design, resource assessment, and quality inspection. It is widely used in various small and medium-sized projects. YG, as a professional core drilling machine manufacturer, focuses on the research and development, and production of HZ core drilling rigs, ensuring higher quality. Contact us now for more information.
Get Factory Direct Pricing Today
YG HZ Core Drilling Rig Technical Parameter
| Model (HZ series products) | HZ-130Y/130YY | HZ-180Y/180YY | HZ-200Y/200YY |
| Depth (m) | 130 | 180 | 200 |
| Opening diameter. (mm) | 220 | 220 | 325 |
| Endend hole dia. (mm) | 75 | 75 | 75 |
| Rod dia (mm) | 42-60 | 42-60 | 42-60 |
| Drilling angle (°) | 90-75 | 90-75 | 90-75 |
| Traction power (kw) | 13.2 | 13.2 | 15 |
| Weight without power distribution (kg) | 560 | 610 | 1150 |
| Unqualified (mm) | 2.4*0.7*1.4 | 2.4*0.6*1.4 | 2.7*0.9*1.6 |
| Speed (r/min) | 142/285/570 | 130/300/480/730/830/1045 | 64/128/287/557 |
| Memory lesson (mm) | 450 | 450 | 450 |
| Maximum tension (kg) | 1600 | 2000 | 2400 |
| Speed of each unit (m/min) | 0.41-1.64 | 0.35-2.23 | 0.12-0.95 |
| The diameter of the wire rope is Rope dia. (mm) | φ9.3 | φ9.3 | φ12.5 |
| Capacity (m) | 27 | 35 | 35 |
| Fixed load (tons) | 2 | 2 | 5 |
| Size specification (L/min) | 95 | 95 | 145 |
| Maximum pressure.Pressure (Mpa) | 1.2 | 1.2 | 2 |
| Time (yuan/min) | 93 | 93 | 93 |
| Water spray hose dia. (mm) | 51 | 51 | 51 |
| Pumping hose dia. (mm) | 32 | 32 | 32 |
