A tire shredding machine is a specialized piece of equipment used to process waste tires. Through powerful blades and mechanical action, it shreds tires into small pieces or granules. These shredded tires can be used to manufacture rubber granules, fuel, or other recycled products. The tire shredding machines we offer are not only cleverly designed and easy to operate, but also highly durable and efficient. Whether processing large-scale industrial waste tires or small-scale household waste, our equipment provides optimal processing results, reducing manual intervention and increasing production efficiency. Tire recycling not only helps reduce environmental pollution from waste but also helps create renewable resources and promotes the development of a circular economy. Contact YG today to get the latest product information and quotes and start your path to success!
Get Factory Direct Pricing Today
YG Tyre Shredding Machine Parameter
| Model | YG-600 | YG-1000 | YG-1200 | YG-1500 | YG-1800 |
| Knife size(mm) | Φ200*20 | Φ300*30 | Φ300*40 | Φ500*50 | Φ600*60 |
| Power (kW) | 11*2 | 37*2 | 45*2 | 75*2 | 90*2 |
| Capacity(t/h) | 0.3-0.5 | 1-1.2 | 2.5-3 | 3.8-4.5 | 6-7 |
| Knife quantity(pcs) | 30 | 26 | 30 | 38 | 45 |
| Machine size(m) | 2.6*1*2.1 | 3.4*1.25*2.2 | 3.8*1.25*2.2 | 4.4*1.5*2.5 | 5.3*2.1*2.8 |
Get Factory Direct Pricing Today
Working Principle of Tire Shredding Machines
The core working principle of a tire shredding machine is to shred and tear waste tires through the relative rotation of the cutter shafts, achieving a crushing effect. Taking the mainstream double-shaft tire shredding machine as an example, its working process is as follows: First, the operator feeds the waste tires into the crushing chamber through the feeding device, and the feeding safety door automatically closes to ensure safety; then, the power system is started, and the motor drives the cutter shafts to rotate at a relatively high speed, with the wear-resistant blades on the shafts interlocking; when the waste tires enter between the cutter shafts, the blades gradually crush the tires into rubber particles of a preset size through the combined force of shearing and tearing; finally, the crushed rubber particles are discharged through the discharge device. If finer particles are required, they can be screened by a screening machine and then fed back into the equipment for further crushing. The working principle of a portable tire shredder is the same as that of a conventional model, only the power system and body design are more focused on portability. It can be powered by a diesel generator, making it suitable for outdoor operations without a power supply. If used in conjunction with a tire recycling equipment production line, the crushed rubber particles can also enter subsequent separation processes to achieve the separation and recycling of rubber, steel wire, and fiber.
Get Factory Direct Pricing Today
Features & Specifications of YG Tyre Shredding Machine
- High-Efficiency Shredding Capacity: Utilizing a dual-shaft/single-shaft precision shearing and shredding design, the shredding efficiency is several times higher than traditional equipment, allowing for rapid shredding of various types of waste tires and significantly shortening the processing cycle.
- Flexible Multi-Model Adaptability: Includes various models such as portable tire shredders and industrial tire shredders, allowing for precise matching based on processing volume, operating environment, and tire type, resulting in high equipment utilization.
- Controllable Shredding Particle Size: By changing different specifications of blades and adjusting the rotational speed of the blade shaft, multiple shredding particle sizes can be achieved, adapting to different recycling needs without the need for subsequent secondary shredding.
- Safe and Environmentally Friendly Design: Equipped with a feeding protection door and overload protection device to prevent material jamming and ensure personnel safety; the operation process includes dust removal and noise reduction devices, ensuring dust and noise emissions meet environmental standards and comply with regulatory requirements.
- Excellent Wear Resistance and Durability: The core blade shaft and blades are made of high-strength wear-resistant materials and undergo special heat treatment, resulting in a long service life; key parts of the machine body are reinforced for strong impact resistance and low failure rate.
- Simple Operation and Maintenance: Intelligent control system with an intuitive and easy-to-understand touchscreen interface; operators can easily learn to use the equipment after simple training; routine maintenance only requires regular inspection of blade wear, lubrication of key parts, and cleaning of equipment residue, resulting in low maintenance costs.
- Key Technical Parameters: Processing capacity covers various specifications, suitable for various tire types, including passenger car tires, truck tires, and engineering tires; adjustable shredding particle size; motor power configured as needed; reasonable equipment weight; and simple installation and commissioning.
Get Factory Direct Pricing Today
8 Frequently Asked Questions about YG Tire Shredders
The shredded fragments can be used to produce TDF fuel, make rubber powder, lay playground tracks, or as raw materials for oil refining and cracking. Using a tire shredding machine is the first step in value transformation.
Yes. YG provides small and medium-sized models such as portable tire shredders, which are affordable and easy to operate, requiring no professional team; the processing capacity can be precisely matched to the needs of small and medium-sized enterprises, and can be upgraded as needed. There’s no need to replace equipment when expanding later, perfectly meeting the development needs of small and medium-sized recycling companies.
It is suitable for small waste recycling stations, temporary outdoor crushing operations, and multi-site mobile operations. Its compact size and mobility, and support for diesel generator power supply, eliminate the need for a fixed power source, effectively reducing material transportation costs and increasing operational flexibility.
It can shred various types of waste tires, including car tires, truck tires, van tires, and engineering tires. Different models are suitable for different sizes and hardness: the portable tire shredder focuses on small and medium-sized tires, while the industrial tire shredder can handle large engineering tires.
Our equipment features a low-noise design, complying with environmental protection requirements and ensuring minimal noise during operation.
Yes, we can customize the equipment’s processing capacity and size according to your needs to meet the requirements of different projects.
The price is mainly affected by factors such as the model type (portable/industrial grade, single-shaft/double-shaft), processing capacity, functional configuration (dust removal and noise reduction, intelligent system), and customization requirements; the price of a tire recycling equipment production line also needs to be calculated in conjunction with the scale of supporting equipment. Direct supply from the manufacturer can provide a cost-effective solution.
When choosing equipment, you need to consider the type of waste tires, processing capacity, and the requirements of the final product. Our sales team will provide you with professional advice.
Get Factory Direct Pricing Today
Tyre Shredding Machine Manufacturer – YG Machinery Factory Price
By choosing our tire shredding machine, you will enjoy an efficient, stable, and environmentally friendly waste tire processing experience. The equipment’s automated operation significantly improves production efficiency and reduces manual intervention, saving substantial labor costs. Its powerful shredding capabilities allow it to process various types of waste tires, bringing significant economic benefits to the tire recycling industry. Beyond the core shredding system, YG always focuses on maximizing your asset utilization. After shredding, you can use our steel wire separator to extract high-purity steel wire for additional profit.
If you have more demanding needs, our product line also includes other types of tire recycling equipment, such as industrial tire shredders and tire recycling machines, which can help you complete more complex recycling tasks. Our factory-direct sales model ensures that you can bypass all intermediaries and directly access the most advanced technology. By choosing our complete solution, you will be able to maximize resource utilization and reduce operating costs. Contact us now to learn more about our equipment and choose the product that best suits your needs, helping you drive more environmentally friendly and efficient projects.
