Dry ice sandblasting machines, also commonly known as dry ice blasting machines or dry ice cleaning machines, utilize the impact and sublimation of dry ice particles (solid carbon dioxide) driven by high-pressure airflow to achieve non-destructive cleaning of surface contaminants, rust, oil, and coatings on workpieces. During the cleaning process, the dry ice directly sublimates into gaseous carbon dioxide, leaving no residue, making it environmentally friendly and pollution-free. It is a new type of environmentally friendly cleaning equipment that replaces traditional chemical cleaning and sandblasting. It can be combined with a dry ice pellet machine to achieve integrated dry ice preparation and cleaning. Suitable for industrial heavy oil and rust cleaning, its derivative, the dry ice cleaning machine for cars, is specifically designed to meet the cleaning needs of the automotive industry. As a professional dry ice cleaning machine series product, it boasts advantages such as efficient cleaning, stable operation, and flexible adaptability. Thanks to its reliable quality and wide applicability, the dry ice sandblasting machine has been exported worldwide. Are you also interested in dry ice cleaning machines? Please contact us now!
Get Factory Direct Pricing Today
Dry Ice Blasting Machine Parameter
| Model | ICE-JET 3.0 | ICE-JET 6.0 | ICE-JET 15 | ICE-JET 40 |
| Dry Ice Capacity | 3KG | 6KG | 15KG | 40KG |
| Dry lce Consumption | 20-50KG/H | 20-50KG/H | 30-100KG/H | 30-100KG/H |
| Supply Pressure | 3-10bar | 13-10bar | 3-10bar | 3-10bar |
| Air Consumption | 1-2m³/min | 1-3m³/min | 1-4m³/min | 1-5m³/min |
| Weight | 40KG | 50KG | 65KG | 80KG |
| Dimensions | 460x340x750mm | 460x350x850mm | 550x445x985mm | 650x550x1000mm |
| Total Power | <500W | <800W | <800W | <800W |
Get Factory Direct Pricing Today
Working Principle of the YG Dry Ice Blasting Machine
- Dry Ice Supply and Airflow Preparation: Dry ice particles enter the conveying pipeline from the storage bin. Simultaneously, the high-pressure airflow system starts, generating a stable high-pressure airflow. The high-pressure airflow and dry ice particles mix in the pipeline to form a gas-solid two-phase flow.
- High-Speed Jet Impact: The mixed dry ice particles, driven by the high-pressure airflow, are sprayed at high speed onto the workpiece surface through the spray gun head. The kinetic energy of the dry ice particles is converted into impact force, impacting the stains, rust, and other impurities on the workpiece surface.
- Low-Temperature Embrittlement and Peeling: Dry ice particles have an extremely low temperature (-78.5℃). Upon contact with the workpiece surface, they rapidly cool the surface, causing stains, coatings, and other impurities to lose their adhesion due to low-temperature embrittlement. Under the impact, these impurities are peeled off from the workpiece surface.
- Sublimation without Residue: The peeled impurities are scattered by the airflow. At the same time, the dry ice particles quickly sublimate into carbon dioxide gas after the impact, leaving no solid or liquid residue. The cleaning process is completed directly without any subsequent cleaning required.
Throughout the entire process, the control system monitors the air pressure and dry ice spray volume in real time, ensuring that the cleaning parameters precisely match the workpiece requirements, achieving efficient, non-destructive, and environmentally friendly cleaning results.
Get Factory Direct Pricing Today
YG Dry Ice Blasting Machine Application Fields
- Machinery Manufacturing Industry: Suitable for rust removal and degreasing of machine tool parts, stamped workpieces, and equipment casings in machining workshops. It can quickly remove metal chips, cutting fluid residues, and other impurities generated during the production process.
- Automotive Industry: Applicable to engine carbon deposit cleaning, chassis oil stain cleaning, old paint removal from car bodies, and pre-assembly cleaning of parts in automotive repair and manufacturing processes. It is especially suitable for non-destructive cleaning of precision components such as engines.
- Food Processing Industry: Used for cleaning and disinfection of food production line equipment, storage tanks, pipelines, and molds. It meets the food industry’s requirements for no chemical residues and hygiene standards, and allows for online cleaning without disassembling the equipment.
- Aerospace Industry: Used for cleaning oil stains, oxide layers, and adhesive residues on high-precision components such as aircraft engine blades, landing gear parts, and avionics components, ensuring that the cleaning process does not damage the precision and performance of the components.
- Electronics Manufacturing Industry: Suitable for cleaning solder residue, dust, and adhesives on circuit boards, electronic components, and semiconductor devices. The low-temperature cleaning characteristics prevent damage to the precision structure and conductivity of electronic components.
- Mold Manufacturing Industry: Used for cleaning cavity residues in injection molds, die-casting molds, and rubber molds. Online cleaning can be achieved without disassembling the molds, protecting the precision of the mold cavities, and extending the mold’s service life.
- Building Renovation Industry: Applicable to rust removal of metal beams and columns in old buildings, cleaning of old paint on walls, and cleaning of ground stains. The cleaning process is dust-free and will not damage the main structure of the building.
- Shipbuilding Industry: Used for rust removal on ship hulls, deck oil stain cleaning, and cleaning of ship engine parts. It can adapt to complex working environments such as outdoor and high-altitude operations in shipbuilding and repair.
Get Factory Direct Pricing Today
Frequently Asked Questions about YG Dry Ice Cleaning Machines
Answer: Dry ice consumption can be precisely adjusted through parameters, adapting to the degree of soiling, saving more compared to traditional cleaning methods. Using a dry ice pellet machine to produce dry ice in-house reduces the cost to only 1/3 of purchasing dry ice externally, significantly lowering costs in the long run.
Answer: It is suitable for cleaning various stains such as oil stains, rust, coatings, carbon deposits, and adhesive residues. The equipment provides non-destructive cleaning and is equipped with precise parameter adjustment functions, allowing it to clean high-precision equipment such as precision instruments and electronic components without damaging the workpiece surface.
Answer: Consider the cleaning target (type of dirt, substrate), required cleaning efficiency (area/time), and available air source pressure and flow rate in your factory. We recommend providing specific examples so that YG engineers can recommend the most suitable dry ice blasting machine model for sale.
Answer: Yes, as a professional dry ice cleaning machine for cars application, it can safely remove oil sludge and carbon deposits from the surface of engines and transmissions without damaging wiring harnesses, sensors, and other precision components. No wiping is required after cleaning, greatly improving the efficiency and quality of deep maintenance.
Answer: The main consumable is dry ice pellets. In the long run, the savings in downtime, labor costs, waste disposal costs, and extended equipment lifespan far outweigh traditional methods, resulting in lower overall ownership costs.
Answer: YG can provide a matching dry ice pellet machine or recommend reliable local dry ice suppliers to ensure you have a stable and high-quality source of dry ice, guaranteeing optimal equipment performance.
Answer: YG provides comprehensive after-sales support, including remote telephone guidance, online parts inquiry and ordering, and on-site repair services according to the service contract, ensuring uninterrupted production.
Get Factory Direct Pricing Today
Dry Ice Sandblasting Machine Manufacturer – YG Machinery Factory Price
In today’s industrial cleaning landscape, where environmental protection, efficiency, and workpiece protection are increasingly important, the YG dry ice sandblasting machine stands out with its core advantages of environmental friendliness, residue-free and non-destructive cleaning, high efficiency, flexibility, stability, and durability. Whether it’s rust and dirt removal in mechanical manufacturing, precision cleaning in the automotive industry, or hygienic cleaning in food processing, the YG dry ice sandblasting machine enables low-cost, high-quality cleaning operations, while also helping businesses align with global environmental trends and mitigate environmental risks.
As a professional industrial cleaning equipment manufacturer, YG not only provides high-quality dry ice sandblasting machines but also offers a full range of supporting equipment, such as dry ice pellet machines and customized cleaning solutions. Our equipment has been exported to numerous countries and regions worldwide, earning widespread trust through its reliable quality and comprehensive service. Click the inquiry button now to submit your cleaning scenario, workpiece type, and requirements to receive a customized solution and accurate quotation.
